RACWK0511CMU Midea 5,000 Btu 115-Volt Window Air Conditioner Replacement Parts
Manufacturer
Model Number
RACWK0511CMU
Description
5,000 Btu 115-Volt Window Air Conditioner
Interactive Exploded View
Parts List
| Category | Part Number | Description | Demand | Availability |
|---|---|---|---|---|
12100105000021 | Midea Axial Flow Fan Schematic Location: 15 | No | ||
| Cabinet | 12220300A01390 | Midea Cabinet Assembly Schematic Location: 9 | No 33.95 | |
| 15120300005522 | Midea Capillary Subassembly Schematic Location: 20.2 | No 12.95 | ||
| 12100103000062 | Midea Centrifuge Fan Schematic Location: 12 | In Stock In stock 6.95 | ||
| 12220300A01391 | Midea Chassis Assembly Schematic Location: 8 | No 31.95 | ||
| Condensor | 15820300001389 | Midea Condenser Assembly Schematic Location: 16 | In Stock In stock 64.95 | |
| Cover,Cap | 12220300000485 | Midea Cover Of Electronic Control Box Schematic Location: 6 | No 6.95 | |
| 15120300005123 | Midea Discharge Pipe Assembly Schematic Location: 18 | No 36.95 | ||
| Control | 17220300001350 | Midea Electronic Control Box Assembly Schematic Location: 5 | No 61.95 | |
| Control | 12220300003558 | Midea Electronic Control Box Subassembly Schematic Location: 5.7 | No 11.95 | |
| Evaporator | 15820300002654 | Midea Evaporator Schematic Location: 20.1 | No 47.95 | |
| Evaporator | 15820300002653 | Midea Evaporator Assembly Schematic Location: 20 | No 66.95 | |
| Compressor - Sealed System | 11103010010054 | Midea Fixed Speed Rotary Compressor Schematic Location: 17 | No 240.95 | |
| 12020300000487 | Midea Installation Accessory Schematic Location: 7 | Y | In Stock In stock 27.95 | |
| Knob, Dial, Button | 12100403A00713 | Midea Knob Assembly Schematic Location: 3 | No | |
| Knob, Dial, Button | 12100403A00714 | Midea Knob Assembly Schematic Location: 3 | Y | In Stock In stock 9.95 |
| Switch | 17400517000016 | Midea Master Rotary Switch Schematic Location: 5.5 | Y | In Stock In stock 12.95 |
| Panel | 12120300A19751 | Midea Panel Subassembly Schematic Location: 1.1 | Y | In Stock In stock 28.95 |
| Panel | 12120300A19754 | Midea Panel Subassembly Schematic Location: 1 | In Stock In stock 28.95 | |
| Led | 17401202000045 | Midea Power Cord Subassembly Schematic Location: 5.2 | Y | In Stock In stock 61.95 |
| Board | 12120300004505 | Midea Rear Barrier Board Subassembly Schematic Location: 14 | No 20.95 | |
| Motor,Ice Maker Motor | 11002012010080 | Midea Single Phase Asynchronous Motor Schematic Location: 13 | No 64.95 | |
| Pipe, Tube, Hose, Fitting | 15120300005162 | Midea Suction Pipe Schematic Location: 19 | No 24.95 | |
| Sensor, Thermistor, Thermostat | 17400513000013 | Midea Temperature Controller Schematic Location: 5.3 | Y | In Stock In stock 16.95 |
| Frame | 12220300003459 | Midea Top Shutter Frame Subassembly Schematic Location: 10 | Y | In Stock In stock 6.95 |
| 12820300000239 | Midea Volute Shell Subassembly(above) Schematic Location: 11 | Y | No | |
| 12820300000299 | Midea Volute Shell Subassembly(above) Schematic Location: 20.3 | No 6.95 |
